If the control grid has high negative potential, then it allows only a few electrons to pass through it.

Thus, the dim spot is produced on the lightning screen. If the negative potential on the control grid is low, then the bright spot is produced. Hence the intensity of light depends on the negative potential of the control grid. After moving the control cathode ray oscilloscope theory the electron beam passing through the focusing and accelerating anodes.

The accelerating anodes are at a high positive potential and hence they converge the beam at a point on the screen. After moving from the accelerating anode, the beam comes under the effect of cathode ray oscilloscope theory deflecting plates.

What is Cathode Ray Oscilloscope (CRO)? Definition, Construction and Working - Circuit Globe

When the deflecting plate is at zero potential, the beam produces a spot at the centre. If the voltage is applied to the cathode ray oscilloscope theory deflecting plate, the electron beam focuses at the upward and when the voltage is applied horizontally the spot of light will be deflected horizontally.

Just type and press 'enter' Search for: CRO is basically an XY 2 dimensional plotter which can plot an input signal vs another signal or an input signal vs time.

A cathode ray oscilloscope is used to study waveforms, transients, time based or frequency based analysis. This circuit is typically found in a waveform monitor cathode ray oscilloscope theory, although some better oscilloscopes include this function.

As described under delayed sweeps, a trigger delay circuit typically the main sweep extends this delay to a known cathode ray oscilloscope theory adjustable interval. In this way, the operator can examine a particular pulse in a long train of pulses.

Some recent designs of oscilloscopes include more sophisticated triggering schemes; these are described toward the end of this article.


cathode ray oscilloscope theory Delayed sweeps[ edit ] More sophisticated analog oscilloscopes contain a second timebase for a delayed sweep. A delayed sweep provides a very detailed look at some small selected portion of the main timebase. The main timebase serves as a controllable delay, after which the delayed timebase starts.

  • Cathode-ray oscilloscope | instrument |
  • Oscilloscope - Wikipedia
  • Cathode-ray oscilloscope
  • Cathode-Ray Oscilloscope
  • Construction of Cathode Ray Oscilloscope

This can start when the delay expires, or can be triggered only after the delay expires. Ordinarily, the delayed timebase is set for a faster sweep, sometimes much faster, such as At extreme cathode ray oscilloscope theory, jitter in the delays on consecutive main sweeps degrades the display, but delayed-sweep triggers can overcome that.


The display shows the vertical signal cathode ray oscilloscope theory one of several modes: When the delayed sweep is active, the main sweep cathode ray oscilloscope theory brightens while the delayed sweep is advancing. In one combination mode, provided only on some oscilloscopes, the trace changes from the main sweep to the delayed sweep once the delayed sweep starts, although less of the delayed fast sweep is visible for longer delays.

Another combination mode multiplexes alternates the main and delayed sweeps so that both appear at once; a trace separation control displaces them.
